Real-time KPIs
Service, platform and infrastructure metrics in a single pane. SMS success, DLR ratio, queue depth, API response times, host utilisation — all kept fresh to the sub-minute.
Service
SMS · DLR
Platform
API · errors
Infra
CPU · RAM
Performance System · Real-time NOC
Real-time monitoring built for messaging, not adapted to it.
Unified, real-time visibility across SMS, voice, platforms and infrastructure. Raw counters, CDRs and platform telemetry become live KPIs, threshold alerts and SLA reports — purpose-built for the NOC, not borrowed from a generic APM.
MNO-grade security GSMA Associate Member Carrier-grade availability
BroadNet · performance
Network performance
99.99%
uptime
300M+
events / day
1,000+
operator connections
Platform uptime
99.99%
Carrier-grade availability for the monitors that watch every other system
Refresh window
<60s
Live KPIs computed from counters, CDRs and platform telemetry in near real-time
KPIs out of box
30+
Service, platform and infrastructure metrics tuned for messaging operations
NOC operations
24/7
Operated by the same team that runs BroadNet's own messaging network
NOC monitoring console
The wallboard your on-call team lives in.
Live KPIs, an alert feed that respects severity, and per-tenant health in one pane — purpose-built for messaging operations. Below is an illustrative snapshot built from sample data.
Example
Operations overview
last 60 minEvents / sec
48,210
Alert latency
3.4s
Active tenants
37
Error rate
0.12%
Throughput
events / sec · last 60 min
now
Tenant health
delivery rate by tenant
Northwind Retail96.1%
Atlas Bank OTP99.4%
Gulf Aggregator98.9%
Sahara Telecom97.2%
Meridian Alerts99.1%
Alerts
most recent first| 09:12:04 | route ZA-MTN | DLR dipped to 88.4% | Warning |
| 09:11:52 | api-gw-3 | p95 latency 512 ms | Major |
| 09:10:31 | SS7 firewall | 3 blocked SRI-SM | Info |
| 09:08:15 | smsc-node-2 | queue depth 12,480 | Warning |
| 09:05:03 | tenant Northwind | SLA credit threshold | Critical |
Illustrative example — sample data, not an audited SLA or a live feed.
Capabilities
Everything a NOC team needs to run a messaging platform at scale.
Six capabilities, one platform. Real-time KPIs, alerts that fire on the right thresholds, SLA tracking your customers can verify, and integration paths that respect the tooling you already operate.
Threshold-based alerts
Static thresholds per KPI with warning, major and critical severities. Per-customer and per-route rules. A custom DSL covers conditions the defaults don't.
Severities
3 tiers
Scope
Per route
DSL
Yes
SLA monitoring
Compliance tracking for the SLAs you signed and the ones you owe. Management reports, partner reports, and customer-facing dashboards with public status if needed.
Internal
Tracked
External
Reported
Status pages
Optional
NOC tool integration
Webhook delivery to ticketing platforms. SNMP v2 and v3 supported. Slots cleanly alongside ManageEngine and other NMS rather than asking you to replace them.
SNMP
v2 · v3
Webhooks
Native
NMS
Coexists
Multi-tenant sharing
Role-based access scoped per dashboard. Selected views can be shared with operators, partners or enterprise customers. Public status pages available per service.
Access
RBAC
Sharing
Per dash
Tenants
Isolated
Workflow integration
Built around how NOC teams actually work. Alerts arrive with context — related metrics, recent changes, similar incidents. Escalation paths and audit trail included.
Context
Auto
Escalation
Tiered
Audit
Logged
Capability matrix
Every metric, its source, and who gets to see it.
Performance System ships with more than thirty KPIs across eight capability groups. Each one is computed from a defined source, evaluated against thresholds or an SLA band, and scoped to the audience that needs it — internal NOC, commercial, partner or customer.
| Capability | What it measures | Primary sources | Alerting | Shared with |
|---|---|---|---|---|
| Service KPIs | SMS success %, DLR ratio, submit-to-deliver latency | SMSC, A2P platform, CDRs | Threshold + SLA | NOC · partners |
| Platform KPIs | API response time, error rate, throughput (msg/sec) | Gateway, API layer, app logs | Threshold | NOC |
| Infrastructure | CPU, RAM, disk and network per host | Host agents, SNMP v2/v3 | Threshold | NOC |
| Queue health | Queue depth, retry backlog, spool age | SMSC counters | Threshold | NOC |
| Security counters | Blocked messages, SS7 anomalies, sender-ID violations | SMS Firewall, SS7 Firewall | Threshold + event | NOC · risk |
| Route quality | Per-route DLR, conversion, cost anomalies | CDRs, route configuration | Threshold | Commercial |
| SLA compliance | Uptime, delivery-SLA band, credit exposure | Aggregated KPI store | SLA report | Customers · partners |
| Business KPIs | Volume trend, revenue-affecting drops, top movers | CDRs, billing feed | Report | Management |
30+ KPIs · 8 capability groups · per-tenant scoping
How it works
From raw counter to on-call alert in under a minute.
The pipeline is deliberately simple to reason about. Sources emit counters, CDRs and telemetry. Collectors pull them on their native protocol. The metrics engine normalises and computes KPIs on a sub-minute window. The surface layer renders live dashboards and evaluates thresholds, then fans results out to the tools your NOC already lives in.
01 · Sources
Data sources
- SMSCs & gateways
- SMS / SS7 firewalls
- Hosts & probes
- CDRs & billing
02 · Collectors
Collectors
- SNMP v2/v3 polls
- Webhook ingest
- DB & counter reads
- Log tail
03 · Engine
Metrics engine
- Normalise & de-dup
- Compute KPIs
- Roll-ups & baselines
- <60s window
04 · Surface
Dashboards & alerts
- Live NOC panes
- Threshold engine
- SLA tracking
- Status pages
05 · Delivery
Downstream
- Ticketing webhooks
- Email & SMS
- Wallboards
- Partner reports
counters → collectors → metrics engine → dashboards → alerts
Monitoring & alerting
Three categories of alert, one operational truth.
Static thresholds for the easy calls. SLA tracking for the contractual ones. Notification and display so the wallboard, the ticket and the inbox all agree.
01
Threshold-based
Static thresholds defined per critical KPI. Multi-level severity classifies alerts the moment they fire so on-call sees what matters first.
warning · major · critical
02
SLA compliance
Continuous tracking of internal and external SLAs. Monthly partner and management reports. Credit-calculation evidence kept on file.
internal + external
03
Notification & display
Delivered to NOC tooling, ticketing systems, email and SMS. On-screen indicators light up live dashboards so the wallboard tells the same story as the inbox.
wallboard · ticketing · email
Worked example
A DLR dip on one route, start to finish.
Thresholds are defined per KPI and per route with three severities. Here is exactly what happens when delivery quality slips on a single destination — the same lifecycle every alert follows.
| Severity | Band | Response | Escalation |
|---|---|---|---|
| Healthy | DLR ≥ 90% | No alert | — |
| Warning | DLR < 90% | Amber tile · webhook | On-call notified |
| Major | DLR < 85% | Ticket auto-raised | Team lead paged |
| Critical | DLR < 80% | Page + escalation | Duty manager paged |
Bands are illustrative. Every threshold, severity and escalation path is configured per customer, per route and per KPI.
- 1t+0sIngest
The metrics engine computes DLR ratio for route ZA-MTN from the last 60 minutes of CDRs. Value: 88.4%.
- 2t+3sEvaluate
88.4% crosses the warning threshold (< 90%). The route is still above the major band (85%), so severity is set to warning.
- 3t+4sNotify
A webhook fires to the ticketing platform, an SMS reaches the on-call engineer, and the wallboard tile for ZA-MTN turns amber.
- 4t+4sContext
The alert carries the 60-minute DLR trend, any recent route or config changes, and links to similar past incidents.
- 5t+9mResolve
Throughput normalises, DLR recovers to 98.1%, the alert auto-closes, and the full lifecycle is written to the signed audit trail.
Who it's for
Built for the teams that own uptime.
MNO & carrier NOC teams
Run the messaging layer beside your existing NMS. Service, platform and security KPIs in one pane, with alerts that respect on-call rotations.
A2P aggregators
Watch per-route DLR, conversion and cost anomalies in real time, and expose partner-facing SLAs without building a reporting stack from scratch.
Enterprise messaging ops
Monitor the delivery quality behind OTP, alerts and campaigns, with customer-facing status pages that make your SLA verifiable.
Managed-service customers
Let BroadNet's NOC operate the monitoring layer for you, escalating only what needs a human — the same team that runs our own network.
Integration points
Reads from everything that matters. Writes to the tools you already use.
Performance System complements your existing infrastructure monitoring. Operators typically run their NMS for hosts and add Performance System for the messaging layer — service KPIs, business KPIs, partner-facing SLAs.
SNMP v2/v3 · webhooks · custom APIs
SMSCs & gateways
BroadNet SMSC Gateway, third-party SMSC performance counters, A2P platform telemetry.
Firewalls
SMS Firewall, SS7 Firewall, sender-ID registries — KPI feeds and security counters.
Infrastructure
Host metrics for CPU, RAM, disk and network. Operator and partner connectivity probes.
NOC & ticketing
ManageEngine and existing NMS. Generic SNMP v2/v3. Webhooks to any HTTP endpoint.
Trust & governance
Operated to the standard the network expects.
The same governance that protects BroadNet's own messaging platform applies to the monitoring layer that watches it. Audit trails, role-based access, residency on request.
Carrier-grade SLA
Designed for 24/7 operations at MNO scale
GSMA Associate Member
Aligned with industry-wide messaging guidelines
Audit trail
Every operational action logged with retention controls
Role-based access
Per-tenant data isolation and per-user visibility
FAQ
Questions NOC leads ask first.
What data sources can Performance System monitor?
SMSCs and gateways, SMS and SS7 firewalls, host infrastructure, CDRs and billing feeds, and any endpoint reachable over SNMP v2/v3 or a webhook. It reads the BroadNet SMSC Gateway natively and connects to third-party platforms through their performance counters and APIs.
How fresh are the KPIs?
Live KPIs are computed from counters, CDRs and platform telemetry on a sub-minute window — typically refreshed inside 60 seconds. Longer-horizon roll-ups and baselines are retained for trend analysis and SLA reporting.
How do threshold alerts work?
Every critical KPI carries static thresholds with warning, major and critical severities, scoped per customer and per route. A custom DSL covers conditions the defaults don't. Alerts fire the moment a value crosses a band and carry context — the recent trend, related changes and similar past incidents.
Does it replace our existing NMS?
No — it complements it. Operators typically keep their NMS for hosts and add Performance System for the messaging layer: service KPIs, business KPIs and partner-facing SLAs. It coexists with ManageEngine and other tools rather than asking you to rip them out.
Can we share dashboards with customers or partners?
Yes. Access is role-based and scoped per dashboard, so selected views can be shared with operators, partners or enterprise customers. Public status pages are available per service where you want customers to verify uptime themselves.
How is access controlled and audited?
Role-based access with per-tenant data isolation governs who sees what. Every operational action is written to a signed audit trail with retention controls, and data residency is available on request — the same governance that protects BroadNet's own messaging platform.
What SLAs can it track?
Both the SLAs you owe customers and the ones your suppliers owe you: uptime, delivery-SLA bands and credit exposure. Monthly management and partner reports are generated automatically, with credit-calculation evidence kept on file.
Related products
Works alongside the rest of the BroadNet stack.
Pricing Module
Automated rate-card management that pairs naturally with performance monitoring.
Local SMSC Firewall
Security counters surfaced as first-class KPIs inside the same dashboards.
SMSC Gateway
Throughput, DLR and queue depth streamed live to NOC operators.
SS7 Firewall
Signaling-layer protection observed alongside application telemetry.
Carrier-grade platform
Infrastructure engineered since 2003.
The same platform that carries 300M+ messages a day, available as building blocks for your stack.
300M+
Msgs·day
99.99%
SLA
23+
Years
Operations infrastructure
Make your NOC dashboards messaging-native.
Real-time KPIs, threshold alerts, SLA reports and integration with your existing monitoring — purpose-built for messaging operations. Run it alongside what you have today.
$ snmpwalk -v3 <noc-host> 1.3.6.1.4.1.broadnet.sms
